Ports | 8x 10/100/1000BASE-T RJ45 | 2x 1G SFP | Swiching Capacity | 20Gbps |
Memory | 128MB | Forwarding Rate | 14.88Mpps |
Flash | 32MB | Jumbo Frame | 9216Bytes |
PoE Standard | N/A | Packet Buffer | 4.1Mbit |
PoE Budget | N/A | MAC Table Entries | 8K |
Housing | Metal | ARP Table Entries | 8K |
Rack Space | 1U | Active VLAN | 4K |
Mounting Methods | Rackmount | Total Number of IPv4 Routes | 512 |
FAN | Fanless | Total Number of IPv6 Routes | 512 |
Dimensions (D*W*H) | 110*90*46mm | Operating Temperature | -40℃-75℃ |
Weight | Storage Temperature | -40 °C ~ 80 °C | |
Input | DC:12-55V
|
Operating Humidity | 5% ~ 95% non-condensing |
Max. Power Consumption | 6.99W(55VDC) | Storage Humidity | 0% ~ 95% non-condensing |
EMC Standard | 47 CFR FCC Part 15B Class A ICES-003 EN 55032 Class A EN 55035 EN 61000-3-2 Class A EN 61000-3-3 IEC/EN 61000-4-2 IEC/EN 61000-4-3 IEC/EN 61000-4-4 IEC/EN 61000-4-5 IEC/EN 61000-4-6 IEC/EN 61000-4-8 IEC/EN 61000-4-11 AS/NZS CISPR 32 VCCI-CISPR32 KS C9832 KS C9835 |
Safty | EN 62368-1 IEC 62368-1 K62368-1 AS/NZS 62368-1 |
Environmental Test | IEC 60068-2-1 Cold IEC 60068-2-2 Dry heat IEC 60068-2-14 Change of Temperature IEC 60068-2-78 Damp heat, steady state |
RoHS | IEC62321 (RoHS 2.0) |
